Paneltronics  |  SKU: 206-051S-PAN

Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S]

$22.99 $34.95
Shipping calculated at checkout.

Delivery and Shipping

All orders placed before 3 PM EST ship the same day

We offer multiple shipping options to ensure you get the part you need at a discount.

Best Way -$11.97

Ground -$14.69

2nd Day Air -$25.89

Overnight -$59.99

In addition, we can ship on your account or via a preferred method upon request.

Found a better price? Need faster shipping?

Call or email! 919-951-4313 or sales@boaterstop.com

Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers


  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
  • Handle Color - Metal with silicon rubber seal
  • Maximum Aperage - 50 Amps
  • Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
  • Rated Switch Cycles - 10,000 actuations at rated current and voltage
  • Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
  • Optional Boot - Black silicone rubber (P/N 048-015)

    Specifications:

    • Color: Stainless
    • Throw/Pole: SPST
    • Box Dimensions: 2"H x 2"W x 2"L WT: 0.2 lbs
    • UPC: 602290201404
